Hydraulic Block Cylinder

prot
Hydraulic Block Cylinder
Product Introduction
• Bore : ø16~ø40 mm    • Pmax : 500 Kg/cm²
• The series of hydraulic cylinder complies with Germany specifications. Employ imported oil seal for outstanding pressure resistance. Standardized specifications and full interchangeability.
• Axial and side mounting type. Choice of single and double acting.
Order Code
Hydraulic Block Cylinder Order Code
1 Series HBC
2 Bore of cylinder ø16, ø25, ø32, ø40
3 Acting type S : Single-acting / D : Double-acting
4 Standard storke Refer to the dimensional table
